Lifetime 90192 - Page 43


TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
ALB
AKB
AKB
AAD
!!8
ABO
ABO
Note: Tighten the 1/2” Centerlock Nut (AAX) until it is fl ush with the end of the Bolt.
!
!!8 (x1)
ABO (x2)
AAD (x1)
v (x2)
SEC
5.10
Secure the Outer Tube (ALB) to the Long Extension Arms (AKB) with the hardware
shown. If needed, use a Rubber Mallet to tap the hardware into place.
7 1/16”
(Not actual length)
