Lifetime 90192 - Page 44


TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
SEC
5.11
7”
(Not actual length)
ABB (x1)
AAZ (x1)
9/16” (x2)
Note: Tighten the 3/8” Centerlock Nut until it is fl ush with the end of the Bolt.
!
AAZ
ABB
AKC
AKC
Insert the 3/8” x 7” Hex Bolt (AAZ) through the holes in the Short Extension
Arms (AKC) that are closest to the Pole. Secure the 3/8” x 7” Hex Bolt to
the Short Extension Arms with the v#ENTERLOCK.UT!"".
