-17-
LIFEWARMER
™
Quantum Battery Pack
ALERT
Conditions
LED INDICATOR MEANING(S) ACTION REQUIRED
Red –STROBE and/or
AUDIBLE ALERT
(Sustained)
FLUID OVER
TEMPERATURE
Stop uid ow. Disconnect Controller
from Battery and from tubing set..
C
heck infusion solution container and line.
If solution container does not feel warm to the touch,
reapply (reconnect) the Quantum System.
N
ote: If audible alert is disabled,
then only RED LED will strobe.
Audible Alert
is enabled
The Red Battery LEDs and Audible Alert will activate briey
each time the Controller is connected to the Battery in the
normal condition with a charged battery as a functional test.
If NO LEDs, the Battery may be out of charge or
malfunctioning.
3 Red LEDs ash
simultaneously during
Start-Up and Audible Alert
Quantum Battery Pack
NORMAL
Conditions
LED INDICATOR MEANING(S) ACTION REQUIRED
Green Solid
(Battery Status)
1 G
reen LED – Battery
Low (insucient to
operate device)
Charge or replace Battery
2 Green LEDs – 50%
charged (approximate)
Sucient to power device, but recommend
charging until fully charged
3 Green LEDs –
Fully charged
N
o action required
Quantum Charger Conditions
LED INDICATOR MEANING(S) ACTION REQUIRED
Green Solid Normal Charging
Continue charging until Battery status indicates fully
charged (three LEDs illuminated). A fully depleted Battery
requires 90 minutes to fully charge
Blue - Flashing Battery charging failure
Disconnect Battery from Charger, wait 5 seconds
and reconnect to Charger.
I
f condition persists, obtain a new Battery.
USER INTERFACE VISUAL/AUDIO LEGEND (continued)
Military and Tactical Medicine users: If the presence of an audible alert presents a hazard, it may be deactivated by
the user. Press and hold the status button continuously for 15 seconds until hearing three quick beeps and seeing
three ashes of the Red LEDs, the audible alert is now disabled. To reactivate, press and hold the status button again
for 15 seconds until one beep occurs and the Red LEDs ash once.
VISUAL/AUDIO INDICATORS
