LIFEWARMER
™
Quantum Charger Conditions
LED INDICATOR MEANING(S) ACTION REQUIRED
NO LED No AC Power or Charger Failure
Check connections to Power Source and Charger.
If power source and connections are conrmed and
condition persists, then replace Charger.
Blue Flashing Battery charging failure
Disconnect Battery from Charger, wait 5 seconds
and reconnect to Charger.
I
f condition persists, obtain a new Battery.
QUANTUM SYSTEM RESPONSE BY TEMPERATURE
TROUBLESHOOTING GUIDE
(continued)
APPENDIX
FLUID
TEMP
HEATING
ELEMENT
LED INDICATIONS
E
D
CONTROLLER BATTERY THERMAL CUT-OUT
≤ 30ºC Active Blue -Flashing
31ºC Active Blue -Flashing
32ºC Active Blue -Flashing
33ºC Active Blue -Flashing
34ºC Active Blue -Flashing
35ºC Active Blue -Flashing
36ºC Active Green- Solid
37ºC Active Green- Solid
38ºC Active Green- Solid
39ºC O Green- Solid
40ºC O Green- Solid
41ºC O Green- Solid
42ºC O Green- Solid
43ºC O Green- Solid
≥ 44ºC O
Green Solid: ≤ 5 min sustained;
After 5 minutes
No LED: >5 min sustained Red Flashing & Audible Alert
> 47ºC O
Green Solid: ≤ 2 min sustained
After 2 minutes
No LED >2 min sustained Red Flashing & Audible Alert
> 48ºC O
Green Solid : ≤ 10 sec sustained
After 10 seconds
No LED: >10 sec sustained Red Flashing & Audible Alert
> 49ºC O
Green Solid: ≤4 sec sustained
After 4 seconds
No LED: >4 sec sustained Red Flashing & Audible Alert
> 50ºC O No LED Red Flashing & Audible Alert Immediately
NOTE 1:
The Thermal Cut-Out cuts power to the
Controller and triggers the Visual/Audible Alert System
(i.e., RED ashing LEDs with Audible Alert on Battery).
NOTE 2:
If the Audible Alert System has been manually
disabled, the Battery will display Red ashing LEDs Only.
No audible alert.
