Lifewarmer Quantum - Component Specifications

-19-
LIFEWARMER
™
Controller
PARAMETER VALUE
Operating Input
Voltage (Vdc)
33.0 (min); 44.4 Typical; 55.0 Max
Input Voltage
Absolute Max (Vdc)
56.0
Operating Current (A) 0.001 minimum / 8.0 Max
Power interruption
tolerance (ms)
30
Charge Voltage (Max) 4.20V +/- 0.03V /cell
Charge Current (Max) 1.6A
Liquid/Solid Ingress Controller with Jacket: IP 53
Weight 2.5 oz
Service (Use) Life 1000 insertions/removals
TIS/TTS-B
PARAMETER VALUE
Sterility – Fluid path/
area underneath
protective end caps
Ethylene Oxide
Biocompatibility ISO 10993
Infusion Set
Compatibility
ISO 8536-4
Liquid/Solid Ingress
With protective cap on
card connector
IP 53
Weight:
≤ 60g (TIS)
≤ 75g (TTS-B)
Service (Use) Life (Per) Single Patient Use
Charger
PARAMETER VALUE
AC Power 100 to 264 Vac, 50, 60 Hz
Equipment Class Class I
Type Part B
Charge Voltage (Max) 50.4Vdc +/- 1%
Liquid/Solid Ingress IP 22
ESD
Level 3, 4KV direct
contact;
+/-8KV air discharge
Weight 20 oz
Service (Use) Life
2500
insertions/removals
Battery
PARAMETER VALUE
Conguration 12 S1P / Li-Pol pouch cells (3.7v)
Chemical System Lithium
Nominal Voltage 44.4 V
Capacity
Rated: 910mAh
Minimum: 850mAh
Conguration 12S1P
Discharge Current
(Max)
6A continuous
9A peak, 200 Hz 50% duty cycle
Discharge Cuto
Voltage
33.0V (2.75V per cell)
Charge Voltage (Max) 4.20V +/- 0.03V /cell
Charge Current (Max) 1.6A
Energy Rating 40.4 Wh
Liquid/Solid Ingress IP 67
Weight 16 0z
Service (Use) Life 3 years/500 cycles
Shelf-Life
Stored batteries with 30%
charge will last 3 months.
Component Specications:
TECHNICAL SPECIFICATIONS
