Lighthouse solair 5100 - Sample Printouts of Standard Reports

Operating Counter
248083389-1 Rev  6-77
Sample Printouts of Standard Reports
Figure 6-96, Figure 6-97 and Figure 6-98 are examples of a Federal
Standard Ft3, ISO 14644-1 and EU GMP 2009 reports.
Note:
If a recipe is
loaded, the name of the
recipe will be printed on
the report.
Figure 6-96 Sample Federal Standard ft
3
Report
*************************
Federal Standard Ft^3
**SOLAIR 3100**
Serial #: 090405005
Targeted Class: 10000
Room Area: 10.00ft^2
Room Stat: Operational
Air Flow: Unidirect
Min Loc: 2
Min Samples/Room: 5
Recipe: FED TEST
-----
07/10/2013, 12:35:47
-----
Particle Size: 0.3
Cumulative, p/ft^3
Vol Req: 0.100 ft^3
Concen Limit: 30800
-----
Loc Samples AvgConcen
LOC001 5 8003.5
LOC002 5 6524.5
-----
Mean: 7264.0
StdDev: 1045.8
StdError: 739.5
95% UCL: 11930.2
Min Vol: 1.467 ft^3
-----
Particle Size: 0.5
Cumulative, p/ft^3
Vol Req: 0.100 ft^3
Concen Limit: 10000
-----
Loc Samples AvgConcen
LOC001 5 328.4
