TruScan 532 Single - Wavelength Operators Manual Rev. No 02 Page 35 of 114
It is a regulatory requirement that the TruScan 532 Single-Wavelength has this safety
feature connector available. Two wires can be wired out from the interlock switch
to the treatment door’s switch and once the door opens the circuitry will be opened
causing the system to be disabled. At this time, the warning message will show on
the LCD control panel display. Once the door shuts the system will go default back
to STANDBY mode. By default setting a dummy “Interlock” connector is supplied
with each console and it must insert in order for the system to operate correctly.
10. Scan Delivery
This connector will monitor and interface signal with Truscan spot size, encoders,
and motor power source.
11. Com Port
This connector will provide signal and interface with console to LCD.
