8. Pattern Rotation Function
This button is used to rotate the pattern and it is located in the mid bottom of the
screen. The button is activated when it is displayed.
9. Pattern Spacing Function
This button is functioned as to select the different spacing between all the pattern
except the single spot and it is located in the mid bottom of the screen. The
button is activated when it is displayed.
10. Pattern Radius Function
This button is functioned as to select the different radius between the circular, arc,
and curve pattern and it is located in the mid bottom of the screen. The button is
activated when it is displayed.
11. Query or Help Function
This function will assist in the event of clarification required and it is always link to
the manual for the cross reference.
12. Customized Parameter Folder
This folder contains all the customized setting or parameter used in treatment or
indication. It is very easy to access and retrieve any file per requested.
13. Save Function
This will save your file upon requested.
14. Shutdown Function Button
This buttom will shutdown the LCD touch panel but not the console.
15. Pattern Display Area
This area will show the preset patterns prior to treat mode.
