TruScan 532 Single - Wavelength – Operators Manual Rev. No 02 Page 84 of 114
C. Endoprobes (Optional)
The endoprobe is sterilized single use device therefore there will be no installation
procedures involved however, do want to make that the endoprobe packaging is not
being opened prior to the treatment.
Two types of Endoprobes carry by Lightmed are:
Straight (P/N 620009)
Curved (P/N 620010)
Ensure that Endoprobe coupling plug is well fitted prior to load to console laser aperture
(refer to fig. 5.17)
Figure 5.17 Endoprobe Coupling Plug Assembling Process
In addition, the Endoprobes are sterilized single use devices so it is not possible to do any
testing of them at installation time. It is recommended that if the doctor is to use
Endoprobes that one unit be used as a reference for checking the Console operation and
for Calibration testing.
