23
2. Setup & Use
3. Optional
Accessories
1. Overview
5. Warranty, Safety
& Specifications
4. Troubleshooting
1. Ensure that the REDMIKE Share is
turned off.
2. Make sure the cradle charger
is plugged into a wall outlet.
Connect one end of the charging
cable into the jack labeled
CHARGER on the side of the
REDMIKE Share and plug the
other end into the charging
jack on the rear of the cradle
charger. The REDMIKE Share’s
rechargeable batteries are factory
installed. The LED on the front of
the Handheld Mic will glow green
when charging.
3. Leave the REDMIKE Share
plugged in overnight (8–10 hrs.)
to obtain a full charge. The green
light will turn off when
fully charged.
REDMIKE Share: Charging
NOTE: If the system was purchased
without a REDMIKE or REDMIKE
VC, the REDMIKE Share will utilize
the charger jacks on the back of the
705iR.
