MX4x4DVI-DL
User’s Manual
Page 13 / 43
SWITCHING
Creating a connection or multiple connections in TAKE mode
1. First press and release the selected source button. The pressed source
button and all destination buttons which are currently connected to this
source will light up. The dark remaining destination buttons are not
connected to this source. This is an informative display about current status
of the selected input. (view only)
2. Press and release the selected destination button or buttons which has to be
connected to the selected source. The preselected destination button(s)
start blinking.
3. Press and release TAKE button to execute the tie or ties. Now the selected
input is switched to the selected output or to the multiple outputs.
Deselecting or muting in TAKE mode
1. First press and release the selected source button. The pressed source
button and all destination buttons which are currently connected to this
source will light up. The dark remaining destination buttons are not
connected to this source. This is an informative display about current status
of the selected input. (view only)
2. Press and release the selected, green lighting destination button which has
to be disconnected from the selected source. The pressed destination or
multiple destinations will turn dark.
3. Press and release TAKE button to execute disconnection.
Info Deselected destinations are disconnected from any source, thus output devices
will display black image or "no signal" message, or automatically will turn off.
Info Multiple switching and deselecting actions can be done simultaneously, during only
one TAKE action.
Creating a connection in AUTOTAKE mode
1. Press and release the selected destination button. The pressed destination
button, and the actually connected source button are lighting green. If no
source is connected ( the output is muted) no source button will light.
2. Press and release the selected input button. The switch action will be
executed immediately. Switching between sources to the selected
destination can be done directly.
Deselecting or muting in AUTOTAKE mode
1. Press and release the selected destination button. The pressed destination
button, and the actually connected source button are lighting green. If no
source is connected ( the output is muted) no source button will light.
