Lightware 4x4DVI-DL User Manual

MX4x4DVI-DL
User’s Manual
Page 5 / 43
1. General description
Lightware MX4x4DVI ( single link) and MX4x4DVI-DL ( dual link ) is a DVI matrix switcher
with 4 DVI inputs and 4 DVI outputs, that routes any input(s) to any combination of output(s).
The router conforms to DVI 1.0 specification, and switches signals between 25 - 165 MHz
pixel clock frequency: from 640x480@60Hz to 1920x1200@60Hz or 2048x1080@60Hz PC
resolutions single link, and up to 3440x2400 pixel in dual link mode.
The input signal is not equalized, therefore only standard length (max 5 meter) DVI cables
can be used.
The switcher has an RS 232 ( or RS422 optional) and an RJ45 LAN port for remote control
applications and a control panel for local control operation. Front panel buttons are
illuminated and easy field relegendable with text for informative system integration.
Box contents
Routing switcher
User's manual
IEC power cable
RS 232 9 pole D-sub Male to Female cable
CD-ROM with control software

Lightware 4x4DVI-DL Specifications

General

Brand	Lightware
Model	4x4DVI-DL
Category	Matrix Switcher
Language	English
