Version 1.0 Page 6 / 43
Features
4 Inputs, 4 Outputs non-blocking cross point matrix architecture - The router
allows any input to be switched to any output or more outputs
simultaneously.
Single link, max 1.65 Gb/s DVI-D transmission (1920x1200 or 2048x1080) -
The MX 4x4 DVI routes any DVI single link signal between 25
and 165 MHz pixel clock frequency conforming to DVI 1.0
standard, MX4x4DVI and MX4x4DVI-DL models
Dual link, max 1.65 Gb/s DVI-D transmission (2560x1600 or 3840x2400) - The
MX 4x4 DVI DL routes any DVI single link or dual link signal
between 25 and 165 MHz pixel clock frequency conforming to
DVI 1.0 standard. MX4x4DVI-DL model only.
Supports all HDTV resolutions: 720p, 1080i and 1080p etc. without HDCP
encoding - Unencrypted HDTV signals up to 165 MHz pixel
clock frequency regardless of resolution are passed through
MX 4x4 DVI
EDID routing - Advanced EDID management with EDID emulation. The user can
emulate any EDID on the switcher's inputs independently, read
out and store any attached monitor's EDID in 100 internal
memory locations, upload and download EDID.dat files using
Remote Control Software.
Front panel buttons control – 4 source select, 4 destination select, Take, Load
preset, Save preset, Panel Lock, Output Lock
Relegendable buttons – Each button has an easy removable flat cap and a
translucent label which can be inserted under it to identify
sources and destinations.
RS 232 or RS422 control – Simple ASCII based RS232 protocol is used for
switching, preset calling, status request, etc.
Ethernet control - TCP/IP Ethernet 10Base-T or 100Base TX (Auto-Sensing)
Fiber cable support – Self powered DVI fiber cables using +5V from DVI sources
( VGA cards, etc.) usually are consuming more than 50 mA,
which load is maximum allowed by DVI 1.0 standard.
MX 4x4 DVI & DL supports +5V 500 mA constant current output
on each DVI output to power long distance fiber optical cables.
Universal power supply – the unit accepts AC voltages from 100 to 240 Volts
with 50 or 60 Hz line frequency on standard IEC connector.
Power failure memory – In case of power failure the unit stores its latest
configuration, and after next power up it loads automatically.
