4. View connection on all outputs ( Audio / DVI / RGB / SDI / Video)
Command {VC}
Response (ALLO1O2O3O4O5O6O7O8)CrLf
Description: Response length depends on the number of outputs installed in the
router. The response above suppose a router having 8 outputs. Indexes show the
actual output and the number at the given index shows which input it is connected
to. If value O5 equals 04 it means that output 5 is connected to input 5.
O1..O8 are two digit ascii characters. (01, 02, 04, etc.)
Example: View connection on output 5.
Command {?05}
Response (O05 I01)CrLf
5. View mutes on all outputs( Audio / DVI / RGB / SDI / Video)
Command {VM}
Response (MUTM1M2M3M4M5M6M7M8)CrLf
Description: Response length depends on the number of outputs installed in the
router. The response above suppose a router having 8 outputs. Indexes show the
actual output and the number at the given index shows its state. If the value M5
equals 1 it means that output 5 is in mute, if 0 output 5 is not muted.
Example:
Command {?M}
Response (MUT 1 0 0 1 0 0 0 0)CrLf
Legend: Current router has 8 outputs. Output 1 and 4 are muted while the other
outputs are unmuted.
6. Mute specified output ( Audio / DVI / RGB / SDI / Video)
Command {#yy}
Response (MUTyy)CrLf
Description:Mute output yy.
Example:Mute output 5.
Command {#05}
Response (MUT05)CrLf
7. Unmute specified output ( Audio / DVI / RGB / SDI / Video)
Command {+yy}
Response (UMTyy)CrLf
Description: Unmute output yy.
Example: Unmute output 5. Output 5 is now switched to the output it was
connected prior to mute command.
Command {+05}
Response (UMT05)CrLf
