Lightware UMX-TPS-TX130

3. Installation UMX-TPS-TX100 series – User's Manual 28

MKS Mounting Option
Floor Box Compatibility Table
The FP-UMX-TPS MKS kit can be ordered separately, please contact sales@lightware.com.
Compatible Service Outlet Boxes
FP-UMX-TPS MKS Kit
Product family Part number Sample picture
MK Cablelink Plus
Screed System
CUB100UK-1
CUB200UK-2

CUB340UK-4
CUB100XUK-1
CUB200XUK-2

CUB340XUK-4
MK Cablelink Single Pan
Boxes






MK Cablelink Onix Plus
Screeded Floor System
NXB200X-2


NXB340X-3
NXB340X-4
INFO:  The transmitter unit can be mounted

unserviced power plate or an unserviced
data plate).
36
59.3
77
178
FP-UMX-TPS-TX100
series transmitter
FP-UMX-TPS MKS
bracket
Mounting Steps - FP-UMX-TPS MKS Kit
Step 1. 
both supplied DIN 7981 3,5x19 PZ2 self tapping screws.
Step 2. Place the transmitter to the bracket.
Step 3. Fasten the all four M3x6 PH xing screws




