Lifting Column LC3 IC | 15
Accessories
LC3 IC comes along with accessory kits to make the integration easy� The kits focus on cobot applications�
Article Number Description Content
1002W8163
All you need to get started with a
Universal Robot cobot� The mounting
plate works with UR3e, UR5e, UR10e,
UR16e� The ELEVATE URCap can be
downloaded from LINAK�com
ELEVATE Kit UR includes:
- Power cable, 2-pole, 5m (CAB0367046-5000)
- Signal cable, 9-pole, 5m (CAB0368539-5000)
- Cable relief + screw
- UR mounting plate with 4 screws M10 x 80mm 8�8
- Base mounting plate with 4 screws M10 x 40mm 8�8
1002W8164
All you need to get started with other
cobots: The mounting plate works with:
Doosan H-, M- and A-Series
Omron/TM: TM12 and TM14
ELEVATE Kit Doosan / Omron / TM includes:
- Power cable, 2-pole, 5m (CAB0367046-5000)
- Signal cable, 9-pole, 5m(CAB0368539-5000)
- Cable relief + screw
- Doosan/ Omron/ TM mounting plate
with 4 pcs� M10 x 80mm 8�8
- Base mounting plate with 4 pcs� M10 x 40mm 8�8
1002W8165
Cable Kit includes:
- Power cable, 2-pole, 5m (CAB0367046-5000)
- Signal cable, 9-pole, 5m (CAB0368539-5000)
- Cable relief + screw
The internal bending radius of the cables must be bigger than 3 times the outer dimension of the cable�
For instance if the outer cable dimension is Ø7, the internal radius of the maximum cable bending is 21 mm�
