Linak TECHLINE ELEVATE - LC3 IC - Features and Options; Usage

Lifting Column LC3 IC | 7
Features and options
Load in push and pull 1,000 N
Max speed 100 mm pr� second (adjustable and independent of load)
Stroke length In steps of 100 mm between 400 mm and 900 mm
Position accuracy +/- 1�5 mm
Profile colour Anodised aluminium
Top and bottom plate
colour
Zink grey bottom plate / aluminium grey top plate
Protection class IP44
Motor 24 V DC Brushless
Built-in dimensions Stroke/2 + 280 mm - minimum BID is 400/2 + 280 = 480 mm
Noise level 53 dB (A)
Weight 29 kg with 900 mm stroke
Dynamic bending
moment
Up to 1,400 Nm (allowed bending moment between cobot and column, while
the column is running in or out)
Static bending moment Up to 3,000 Nm (allowed bending moment between cobot and column, while
the column is not moving)
Mounting directions The column can be mounted vertically with a top plate upright or upside down
Cobot compatibility Mounting plates and URCap for Universal Robots e-Series / Mounting plates for
Doosan, Omron, Techman�
-For other options please contact TECHLINE
®
sales @ LINAK
®
A/S
IC interfaces: I/O
Modbus TCP/IP
Usage
Duty cycle 10 % at Full Load (2 minutes use, 18 minutes not in use)
20 % at Half load (4 minutes use, 16 minutes not in use)
Current consumption 6-20 A
Operation temperature +5 °C to + 40 °C
Storage temperature -40 °C to + 70 °C
Relative humidity 20 % to 80 % - non-condensing
Atmospheric pressure 700 to 1060 hPa
Meters above sea level Max� 3000 meters
Approvals EN 55016-2-3:2017+A1, EN 55016-2-1:2014
EN 61000-4-2:2009, EN IEC 61000-4-3:2020, EN 61000-4-4:2012
EN 61000-4-5:2014+A1, EN 61000-4-6:2014, EN 61000-4-8:2010
EN IEC 63000:2018
EN 61000-6-2:2019 – Part 6-2
EN 61000-6-4:2019 – Part 6-4
BS EN 55016-2-3:2017+A1, BS EN 55016-2-1:2014
BS EN 61000-4-2:2009, BS EN IEC 61000-4-3:2020, BS EN 61000-4-4:2012
BS EN 61000-4-5:2014+A1, BS EN 61000-4-6:2014, BS EN 61000-4-8:2010
BS EN IEC 63000:2018
BS EN 61000-6-2:2019 – Part 6-2
BS EN 61000-6-4:2019 – Part 6-4
