Functional description
Hand Control HB10RF:
Up – down head motor
Up – down foot motor
Simultaneous up/down
How to store
• Drive to the desired position
• Push “S”
• Immediately afterwards the desired memory position must be pushed (1, 2 or 3)
• The position is now stored
Drive to stored memory position
Push (1, 2 or 3) keep the button down until the position has been reached.
Hand Control HB20RF:
common operation up/down (option)
Store Button
Memory positions
(3 positions)
3
2
1
S
Up – down head motor
Up – down foot motor
up to 3 extra channels
Light Button
Hand Control HC20RF:
common operation up/down (option)
Store Button
Memory positions (3 positions)
Up – down head motor
Up – down foot motor
up to 3 extra channels
Light Button
Torch - Light Button
