Linde H 70 D - 4.9.2.1.2.1 Mechanical Ignition Timing

Service Training
Section 4.9
Page 19
12.05
4.9.2.1.2.1 MECHANICAL IGNITION TIMING
SPECIAL TOOLS REQUIRED
Timing pin for ignition system
Part no. 000 008 61 00
Torx driver for ignition system
ET-Nr. 276 10 122
The firing point caracteristic curve is controlled
by a resistor. The picture besides shows the
position of the resistor in the truck.
