Linear DMC1 User Manual

2
DMC1H Rough-in Kit for DMC1 without CD/MP3 Player
DMC1HCKIT Rough-in Kit for DMC1 with CD/MP3 Player
DMC1HC Rough-in Kit for DMC1 with CD/MP3 Player
DMC1HKIT Rough-in Kit for DMC1 without CD/MP3 Player
INSTALLATION ROUGH-IN KITS
The DMC1 can be installed with or without a DMC1MP3 CD/
MP3 Player. Two rough-in kits are available for each type of
installation.
The Model DMC1H kit includes:
• One metal wall housing for DMC1
• One FM Dipole Antenna
• 25 feet of AM Antenna Wire with a Ferrite Filter
• 75 feet of MS4DCXSC Shielded Speaker Cable
• Four 1-1/2” snap-in bushings
• One TE5D Transformer Assembly
The Model DMC1HKIT kit includes:
• One metal wall housing for DMC1
• One ME3 Door Station Enclosure
• One DMC1HRW Flush-mount Rough-in Enclosure
• Four DMC1HR Rough-in Rings
• One FM Dipole Antenna
• 25 feet of AM Antenna Wire with a Ferrite Filter
• 75 feet of MS4DCXSC Shielded Speaker Cable
• Four 1-1/2” snap-in bushings
• One TE5D Transformer
The Model DMC1HC kit includes:
• One metal wall housing for DMC1 with DMCMP3
• One FM Dipole Antenna
• 25 feet of AM Antenna Wire with a Ferrite Filter
• 75 feet of MS4DCXSC Shielded Speaker Cable
• One TE2D Transformer
• One TE5D Transformer
The Model DMC1HCKIT kit includes:
• One metal wall housing for DMC1 with DMCMP3
• One ME3 Door Station Rough-in Enclosure
• One DMC1HRW Flush-mount Rough-in Enclosure
• Four DMC1HR Rough-in Rings
• One FM Dipole Antenna
• 25 feet of AM Antenna Wire with a Ferrite Filter
• 75 feet of MS4DCXSC Shielded Speaker Cable
• One TE2D Transformer
• One TE5D Transformer
