LH40DA OWNER’S/OPERATOR’S MANUAL 18.0
12. MAINTENANCE
4. Reinstall the fill plug. Torque Fill plug to 16~22 ft. lbs. (22~30N.m)
5. Check for leaks.
Handlebar Adjustment
Your ATV has handlebars
which can be adjusted for
your personal fit.
1. Remove the handlebar cover.
2. Loosen the four bolts.
3. Adjust handlebar to desired
height. Be sure handlebars do
not hit gas tank or any other part
of machine when turned fully to left or right.
4. Torque handlebar adjuster block to 10-12 ft.Ibs(14-16Nm).
NOTE: Tighten bolts so there is an equal gap at the front and rear of the
handlebar block. Improper gap will result in improper fit of upper pod.
The following items should be checked occasionally for tightness; or if
they have been loosened for maintenance service.
Wheel Nut Torque Specifications（ On Independent Suspension
model ）
Front （ALUMINIUM
WHEEL） M12X1.25
Rear （ALUMINIUM
WHEEL） M12X1.25
