98
VLAN
VLAN
Enabled or disabled (default).
Untagged VLAN
Enabled (default) or disabled.
When enabled, and if its VLAN ID is equal to Untagged
VLAN ID, all traffic is untagged when sent from LAN
ports. Untagged traffic can be accepted by LAN ports. If
disabled, traffic is always tagged when sent from LAN
port and only tagged traffic can be accepted from LAN
port.
By default all traffic on the access point uses VLAN 1,
the default untagged VLAN. This means that all traffic is
untagged until you disable the untagged VLAN, change
the untagged traffic VLAN ID, or change the VLAN ID for
a SSID.
Untagged VLAN
ID
Displays the untagged VLAN ID. Traffic on the VLAN
that you specify in this field is not be tagged with a VLAN
ID when forwarded to the network. VLAN 1 is the default
ID for untagged VLAN and management VLAN.
Management
VLAN
Displays the Management VLAN ID. The VLAN
associated with the IP address you use to connect to the
access point. Provide a number between 1 and 4094 for
the Management VLAN ID. The default is 1.
This VLAN is also the default untagged VLAN. If you
already have a management VLAN configured on your
network with a different VLAN ID, you must change the
VLAN ID of the management VLAN on the access point.
IPv4
IP Address
The IP address of the wireless access point.
Subnet Mask
The Network Mask (Subnet Mask) for the IP address
above.
Default Gateway
Enter the gateway for the LAN segment to which the
wireless access point is attached (the same value as the
PCs on that LAN segment).
Primary DNS
The primary DNS address provided by the DHCP server
or configured manually.
Secondary DNS
The secondary DNS address provided by the DHCP
server or configured manually.
