Linksys LAPAC1750 User Manual

Authentication
This feature supports following two kinds of authentication:
•
Authentication via MAC Address
Select this if you want to use MAC Address for
authentication.
The access point uses lowercase MAC address for
Name and Password, like xxxxxxxxxxxx.
•
Authentication via Name and Password
Select this if you want to use name and password for
authentication.
Name -
Enter the login name. The name includes 1 to 63
characters. Special characters are allowed.
Password - Enter the desired login password. The
password includes 4 to 63 characters. Special
characters are allowed.
Discovery Settings
Bonjour
Enable if administrator wants the access point to be
discovered by Bonjour enabled devices automatically. If
VLAN is enabled, the discovery packets will be sent out via
management VLAN only. The access point supports http
and https services.
LLDP
Enable if administrator wants the access point to be
discovered by s
witch by LLDP protocol. Information such as
product name, device name, firmware version, IP address,
MAC address and so on will be advertised.
LLDP-MED
Enable if administrator wants the access point to be
discovered by switch by LLDP-MED protocol. Information
such as product name, device name, firmware version, IP
address, MAC address and so on will be advertised.
IGMP/MLD Snooping
26

Linksys LAPAC1750 Specifications

General

Modulation	-
Frequency band	2.412 - 2.462, 5.18 - 5.24, 5.745 - 5.825 GHz
Channels quantity	11 channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3at, IEEE 802.3u
Wi-Fi data rate (max)	500 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Quality of Service (QoS) support	Yes
Internal	No
Placement	Ceiling, Wall
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Supported network protocols	IPv6
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	802.1x RADIUS, WDS, WEP, WPA, WPA2
Number of SSID supported	16
Antenna features	Integrated antenna
Input current	1.5 A
AC input voltage	12 V
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	243.08 mm
Width	236.98 mm
Height	43.69 mm
