Linksys LAPAC1750 User Manual

WEP
Authentication
Select Open System or Shared Key. All wireless stations
must use the same method.
Default
Transmit Key
Select a transmit key.
WEP Encryption
Select an encryption option, and ensure your wireless
stations have the same setting:
64-Bit Encryption - Keys are 10 Hex characters.
128-Bit Encryption - Keys are 26 Hex characters.
Passphrase
Generate a key or keys, instead of entering them directly.
Enter a word or group of printable characters in the
Passphrase box and click the Generate button to
automatically configure the WEP key. It consists of 1 to
30 characters.
Key Value
Enter a key in hexadecimal format.
Note--Due to hardware limitation, one set of WEP key is
supported per radio.
WPA2-Personal
This is a further development of WPA-Personal, and offers even greater security.
33

Linksys LAPAC1750 Specifications

General

Modulation	-
Frequency band	2.412 - 2.462, 5.18 - 5.24, 5.745 - 5.825 GHz
Channels quantity	11 channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3at, IEEE 802.3u
Wi-Fi data rate (max)	500 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Quality of Service (QoS) support	Yes
Internal	No
Placement	Ceiling, Wall
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Supported network protocols	IPv6
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	802.1x RADIUS, WDS, WEP, WPA, WPA2
Number of SSID supported	16
Antenna features	Integrated antenna
Input current	1.5 A
AC input voltage	12 V
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	243.08 mm
Width	236.98 mm
Height	43.69 mm
