Linksys LAPAC1750 User Manual

WPA/WPA2-Personal
WPA Algorithm
The encryption method is TKIP or AES.
Pre-shared Key
Enter the key value. It is 8 to 63 ASCII characters or
64 HEX characters. Other wireless stations must use
the same key.
Key Renewal
Specify the value of Group Key Renewal. It’s a value
from 600 to 36000, and default is 3600.
WPA automatically changes secret keys after a certain
period of time. The group key interval is the period of
time in between automatic changes of the group key,
which all devices on the network share.
Constantly keying the group key protects your
network against intrusion, as the would-be intruder
must cope with an ever-changing secret key.
WPA2-Enterprise
This version of WPA2-Enterprise requires a RADIUS Server on your LAN to provide the client
authentication. Data transmissions are encrypted using the WPA2 AES standard.
35

Linksys LAPAC1750 Specifications

General

Modulation	-
Frequency band	2.412 - 2.462, 5.18 - 5.24, 5.745 - 5.825 GHz
Channels quantity	11 channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3at, IEEE 802.3u
Wi-Fi data rate (max)	500 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Quality of Service (QoS) support	Yes
Internal	No
Placement	Ceiling, Wall
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Supported network protocols	IPv6
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	802.1x RADIUS, WDS, WEP, WPA, WPA2
Number of SSID supported	16
Antenna features	Integrated antenna
Input current	1.5 A
AC input voltage	12 V
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	243.08 mm
Width	236.98 mm
Height	43.69 mm
