Linksys LAPAC1750 User Manual

Radio
Wireless Radio
Select the desired radio from the list.
Radio 1 is for 2.4 GHz, and Radio 2 is for 5 GHz.
Rate Limit
SSID
The index of SSID.
SSID Name
The name of the SSID.
Upstream
Rate
Enter a maximum upstream rate for the SSID. The range is
from 0 to 300 Mbps for Radio 1 and from 0 to 800 Mbps
for Radio 2; 0 means no limitation.
Downstream
Rate
Enter a maximum downstream rate for the SSID. The range
is from 0 to 300 Mbps for Radio 1 and from 0 to 800 Mbps
for Radio 2; 0 means no limitation.
QoS
Go to Configuration > Wireless > QoS (Quality of Service) to specify priorities for different traffic
coming from your wireless client. Lower priority traffic will be slowed down to allow greater
throughput or less delay for high priority traffic.
48

Linksys LAPAC1750 Specifications

General

Modulation	-
Frequency band	2.412 - 2.462, 5.18 - 5.24, 5.745 - 5.825 GHz
Channels quantity	11 channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3at, IEEE 802.3u
Wi-Fi data rate (max)	500 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Quality of Service (QoS) support	Yes
Internal	No
Placement	Ceiling, Wall
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Supported network protocols	IPv6
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	802.1x RADIUS, WDS, WEP, WPA, WPA2
Number of SSID supported	16
Antenna features	Integrated antenna
Input current	1.5 A
AC input voltage	12 V
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	243.08 mm
Width	236.98 mm
Height	43.69 mm
