Linksys LAPAC1750 User Manual

QoS Setting
Wireless Radio
Select the desired radio from the list.
Radio 1 is for 2.4 GHz, and Radio 2 is for 5 GHz.
QoS Settings
SSID
The index of SSID.
SSID Name
The name of the SSID.
VLAN ID
The VLAN ID of the SSID.
Priority
Select the priority level from the list. VLAN must be enabled
in order to set priority.
The 802.1p will be included in the VLAN header of the
packets which are received from the SSID and sent from
Ethernet or WDS interface.
WMM
Enable or disable WMM.
WMM (Wi-Fi Multimedia) is a component of the IEEE
802.11e wireless LAN standard for QoS.
WMM provides prioritization of wireless data packets from
different applications based on four access categories:
voice, video, best effort, and background. For an application
to receive the benefits of WMM QoS, both it and the client
running that application have to have WMM enabled.
Legacy applications that do not support WMM and
applications that do not require QoS, are assigned to the
best effort category, which receives a lower priority than
voice and video.
WMM is enabled by default.
WDS
Go to Configuration > Wireless > WDS (Wireless Distribution System) to expand a wireless
network through multiple access points instead of linking them with a wired backbone.
WDS only works and interacts with LAPN300, LAPN600, LAPAC1200 or LAPAC1750 devices.
The access point can act as WDS Root or WDS Station:
•
WDS Root - Receives WDS connections from remote WDS Stations.
•
WDS Station - Connects to remote WDS Root. Supports up to 4 WDS Stations on each
wireless radio.
50

Linksys LAPAC1750 Specifications

General

Modulation	-
Frequency band	2.412 - 2.462, 5.18 - 5.24, 5.745 - 5.825 GHz
Channels quantity	11 channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3at, IEEE 802.3u
Wi-Fi data rate (max)	500 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Quality of Service (QoS) support	Yes
Internal	No
Placement	Ceiling, Wall
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Supported network protocols	IPv6
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	802.1x RADIUS, WDS, WEP, WPA, WPA2
Number of SSID supported	16
Antenna features	Integrated antenna
Input current	1.5 A
AC input voltage	12 V
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	243.08 mm
Width	236.98 mm
Height	43.69 mm
