Linksys LAPAC1750 User Manual

Spanning Tree (recommended if you configure WDS connections)
Spanning Tree
When enabled, STP helps prevent switching loops.
WDS Settings
Radio
Select the desired radio from the list.
Radio 1 is for 2.4 GHz, and Radio 2 is for 5 GHz.
WDS Root
Interface
Status
Enable or Disable the WDS Root.
Be sure the following settings on WDS Root device are
determined and configured. The WDS Station must use the
same settings as Root afterwards.
•
Radio
•
IEEE 802.11 Mode
•
Channel Bandwidth
•
Channel
Note--It is highly recommended that static channel is
configured on both APs. Do not use Auto channel option
when you enable WDS, as both APs in a WDS link must be
on the same radio channel. If Auto option is configured,
there is chance two access points run on different channels
and WDS link cannot establish.
Workgroup Bridge and WDS will not work at the same time
on one wireless radio. When Workgroup Bridge is enabled,
WDS will be disabled automatically on the same radio.
Local SSID
Enter name of the WDS Root SSID (used when connected
by WDS Stations).
Local MAC
Address
MAC address of the WDS Root SSID.
Local Channel
The channel used by WDS Root SSID. WDS stations must
use same channel as the WDS Root.
Channel can be changed in "Basic Settings" page.
52

Linksys LAPAC1750 Specifications

General

Modulation	-
Frequency band	2.412 - 2.462, 5.18 - 5.24, 5.745 - 5.825 GHz
Channels quantity	11 channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3at, IEEE 802.3u
Wi-Fi data rate (max)	500 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Quality of Service (QoS) support	Yes
Internal	No
Placement	Ceiling, Wall
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Supported network protocols	IPv6
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	802.1x RADIUS, WDS, WEP, WPA, WPA2
Number of SSID supported	16
Antenna features	Integrated antenna
Input current	1.5 A
AC input voltage	12 V
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	243.08 mm
Width	236.98 mm
Height	43.69 mm
