Linksys LAPAC2600 User Manual

Backup/Restore to/from Local PC
Backup
Configuration
Once you have the access point working properly, you
should back up the settings to a file on your computer.
You can later restore the access point's settings from
this file, if necessary.
To create a backup file of the current settings:
•
Choose a source file. It can be Backup
Configuration or Current Configuration.
•
Click Backup.
•
If you don't have your browser set up to save
downloaded files automatically, locate where
you want to save the file, rename it if you like,
and click Save.
Restore
Configuration
To restore settings from a backup file:
1. Choose a destination file. It can be Backup
Configuration or Current Configuration.
2. Click Choose File.
3. Locate and select the previously saved backup
file.
4. Click Restore.
Backup/Restore to/from TFTP server
Backup
Configuration
To create a backup file of the current settings:
1. Choose a source file. It can be Backup
Configuration or Current Configuration.
2. Enter the destination file name you plan to save
in TFTP server.
3. Enter the IP address for the TFTP server. Only
IPv4 addresses are supported.
4. Click Backup.
107

Linksys LAPAC2600 Specifications

General

2.4 GHz	Yes
Frequency band	2.412 - 2.462, 5.18 - 5.24, 5.745 - 5.825 GHz
Channels quantity	13 channels
Number of VLAN IDs	17
Fit AP mode features	Wireless distribution system (WDS)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.1x, IEEE 802.3at
Receiver sensitivity	802.11b 11Mbps: -85dBm 802.11a/g 54Mbps: -73dBm 802.11n HT20 MCS7: -67dBm 802.11n HT40 MCS7: -65dBm 802.11n HT40 MCS7: -65dBm
Virtual LAN features	SSID-based VLAN assignment
Wi-Fi data rate (max)	1733 Mbit/s
Ethernet LAN data rates	1000 Mbit/s
Maximum data transfer rate	2533 Mbit/s
Output current	2.5 A
Output voltage	12 V
Power consumption (max)	25 W
Internal	No
Placement	Ceiling, Wall
Certification	FCC: 47 CFR FCC Part 15, Subpart B, Class B; 47 CFR FCC Part 15, Subpart C; 47 CFR FCC Part 15, Subpart E CE: EN55022, Class B; EN61000-3-2; EN61000-3-3; 55024; EN 301 489-1 / EN 301 489-17, Class B; EN 300 328; EN 301 893; EN 62311; EN 50385
Product color	White
LED indicators	System
Cable lock slot type	Kensington
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Antenna features	Integrated antenna
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Security algorithms	802.1x RADIUS, HTTPS, SNMP, WPA, WPA2
Number of SSID supported	16
Service Set Identifier (SSID) features	Hidden SSID
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	243 mm
Width	237 mm
Height	43.69 mm
Weight	848 g
