Linksys LAPAC2600 User Manual

Location
Enter the area or location where the access point
resides.
The location includes 1 to 32 characters. Special
characters are allowed.
SNMP v1/v2 Settings
Get Community
Enter the name of Get Community. Get Community is
used to read data from the access point and not for
writing data into the access point.
Get Community includes 1 to 32 characters. Special
characters are allowed.
Set Community
Enter the name of Set Community. Set Community is
used to write data into the access point.
The Set Community includes 1 to 32 characters.
Special characters are allowed.
SNMP v3 Settings
SNMP v3 Settings
Configure the SNMPv3 settings if you want to use
SNMPv3.
Username: Enter the username. It includes 0 to 32
characters. Special characters are allowed.
Authentication Protocol: None or HMAC-MD5.
Authentication Key: 8 to 32 characters. Special
characters are allowed.
Privacy Protocol: None or CBC-DES.
Privacy Key: 8 to 32 characters. Special characters are
allowed.
Access Control
Access Control
When SNMP is enabled, any IP address can connect to
the access point MIB database through SNMP. You can
enable access control to allow specified IP addresses.
Two IPv4 and two IPv6 addresses can be specified.
SNMP Trap
Trap Community
Enter the Trap Community server. It includes 1 to 32
characters. Special characters are allowed.
Trap Destination
Two Trap Community servers are supported: can be
IPv4 or IPv6.
20

Linksys LAPAC2600 Specifications

General

2.4 GHz	Yes
Frequency band	2.412 - 2.462, 5.18 - 5.24, 5.745 - 5.825 GHz
Channels quantity	13 channels
Number of VLAN IDs	17
Fit AP mode features	Wireless distribution system (WDS)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.1x, IEEE 802.3at
Receiver sensitivity	802.11b 11Mbps: -85dBm 802.11a/g 54Mbps: -73dBm 802.11n HT20 MCS7: -67dBm 802.11n HT40 MCS7: -65dBm 802.11n HT40 MCS7: -65dBm
Virtual LAN features	SSID-based VLAN assignment
Wi-Fi data rate (max)	1733 Mbit/s
Ethernet LAN data rates	1000 Mbit/s
Maximum data transfer rate	2533 Mbit/s
Output current	2.5 A
Output voltage	12 V
Power consumption (max)	25 W
Internal	No
Placement	Ceiling, Wall
Certification	FCC: 47 CFR FCC Part 15, Subpart B, Class B; 47 CFR FCC Part 15, Subpart C; 47 CFR FCC Part 15, Subpart E CE: EN55022, Class B; EN61000-3-2; EN61000-3-3; 55024; EN 301 489-1 / EN 301 489-17, Class B; EN 300 328; EN 301 893; EN 62311; EN 50385
Product color	White
LED indicators	System
Cable lock slot type	Kensington
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Antenna features	Integrated antenna
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Security algorithms	802.1x RADIUS, HTTPS, SNMP, WPA, WPA2
Number of SSID supported	16
Service Set Identifier (SSID) features	Hidden SSID
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	243 mm
Width	237 mm
Height	43.69 mm
Weight	848 g
