Linksys LAPAC2600 User Manual

802.1x Supplicant
802.1x
Supplicant
Enable if your network requires this access point to use
802.1X authentication in order to operate.
Authentication
This feature supports following two kinds of authentication:
•
Authentication via MAC Address
Select this if you want to use MAC Address for
authentication.
The access point uses lowercase MAC address for
Name and Password, like xxxxxxxxxxxx.
•
Authentication via Name and Password
Select this if you want to use name and password for
authentication.
Name -
Enter the login name. The name includes 1 to 63
characters. Special characters are allowed.
Password - Enter the desired login password. The
password includes 4 to 63 characters. Special
characters are allowed.
Discovery Settings
Bonjour
Enable if administrator wants the access point to be
discovered by Bonjour enabled devices automatically. If
VLAN is enabled, the discovery packets will be sent out via
management VLAN only. The access point supports http
and https services.
LLDP
Enable if administrator wants the access point to be
discovered by s
witch by LLDP protocol. Information such as
product name, device name, firmware version, IP address,
MAC address and so on will be advertised.
LLDP-MED
Enable if administrator wants the access point to be
discovered by switch by LLDP-MED protocol. Information
such as product name, device name, firmware version, IP
address, MAC address and so on will be advertised.
28

Linksys LAPAC2600 Specifications

General

2.4 GHz	Yes
Frequency band	2.412 - 2.462, 5.18 - 5.24, 5.745 - 5.825 GHz
Channels quantity	13 channels
Number of VLAN IDs	17
Fit AP mode features	Wireless distribution system (WDS)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.1x, IEEE 802.3at
Receiver sensitivity	802.11b 11Mbps: -85dBm 802.11a/g 54Mbps: -73dBm 802.11n HT20 MCS7: -67dBm 802.11n HT40 MCS7: -65dBm 802.11n HT40 MCS7: -65dBm
Virtual LAN features	SSID-based VLAN assignment
Wi-Fi data rate (max)	1733 Mbit/s
Ethernet LAN data rates	1000 Mbit/s
Maximum data transfer rate	2533 Mbit/s
Output current	2.5 A
Output voltage	12 V
Power consumption (max)	25 W
Internal	No
Placement	Ceiling, Wall
Certification	FCC: 47 CFR FCC Part 15, Subpart B, Class B; 47 CFR FCC Part 15, Subpart C; 47 CFR FCC Part 15, Subpart E CE: EN55022, Class B; EN61000-3-2; EN61000-3-3; 55024; EN 301 489-1 / EN 301 489-17, Class B; EN 300 328; EN 301 893; EN 62311; EN 50385
Product color	White
LED indicators	System
Cable lock slot type	Kensington
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Antenna features	Integrated antenna
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Security algorithms	802.1x RADIUS, HTTPS, SNMP, WPA, WPA2
Number of SSID supported	16
Service Set Identifier (SSID) features	Hidden SSID
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	243 mm
Width	237 mm
Height	43.69 mm
Weight	848 g
