Linksys LAPAC2600 User Manual

WPA2-Personal
Fast
Roaming(802.11r)
Enable or disable Fast Roaming (802.11r) .
Fast Roaming (802.11r) minimizes the delay when a
voice client transitions from one BSS to another within
the same ESS. Fast BSS Transition establishes
security and QoS states at the target AP before or
during a re-association. This minimizes the time
required to resume data connectivity when a BSS
transition happens.
Important Points to Remember:

Fast Roaming (802.11r) is operational only if the
wireless client has support for 802.11r
standard. If the client does not have support for
802.11r standard, it falls back to normal WPA2
authentication method.

If Fast Roaming (802.11r) is enabled, some
clients without 802.11r supported may fail to
connect to the network.

Only one SSID of the AP can be enabled with
Fast Roaming (802.11r).
WPA Algorithm
The encryption method is AES. Wireless stations must
also use AES.
Pre-shared Key
Enter the key value. It is 8 to 63 ASCII characters or
64 HEX characters. Other wireless stations must use
the same key.
Key Renewal
Specify the value of Group Key Renewal. It’s a value
from 600 to 36000 and default is 3600.
WPA automatically changes secret keys after a certain
period of time. The group key interval is the period of
time in between automatic changes of the group key,
which all devices on the network share.
Constantly keying the group key protects your
network against intrusion, as the would-be intruder
must cope with an ever-changing secret key.
37

Linksys LAPAC2600 Specifications

General

2.4 GHz	Yes
Frequency band	2.412 - 2.462, 5.18 - 5.24, 5.745 - 5.825 GHz
Channels quantity	13 channels
Number of VLAN IDs	17
Fit AP mode features	Wireless distribution system (WDS)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.1x, IEEE 802.3at
Receiver sensitivity	802.11b 11Mbps: -85dBm 802.11a/g 54Mbps: -73dBm 802.11n HT20 MCS7: -67dBm 802.11n HT40 MCS7: -65dBm 802.11n HT40 MCS7: -65dBm
Virtual LAN features	SSID-based VLAN assignment
Wi-Fi data rate (max)	1733 Mbit/s
Ethernet LAN data rates	1000 Mbit/s
Maximum data transfer rate	2533 Mbit/s
Output current	2.5 A
Output voltage	12 V
Power consumption (max)	25 W
Internal	No
Placement	Ceiling, Wall
Certification	FCC: 47 CFR FCC Part 15, Subpart B, Class B; 47 CFR FCC Part 15, Subpart C; 47 CFR FCC Part 15, Subpart E CE: EN55022, Class B; EN61000-3-2; EN61000-3-3; 55024; EN 301 489-1 / EN 301 489-17, Class B; EN 300 328; EN 301 893; EN 62311; EN 50385
Product color	White
LED indicators	System
Cable lock slot type	Kensington
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Antenna features	Integrated antenna
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Security algorithms	802.1x RADIUS, HTTPS, SNMP, WPA, WPA2
Number of SSID supported	16
Service Set Identifier (SSID) features	Hidden SSID
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	243 mm
Width	237 mm
Height	43.69 mm
Weight	848 g
