Linksys LAPAC2600 User Manual

QoS Setting
Wireless Radio
Select the desired radio from the list.
Radio 1 is for 2.4GHz, and Radio 2 is for 5GHz.
QoS Settings
SSID
The index of SSID.
SSID Name
The name of the SSID.
VLAN ID
The VLAN ID of the SSID.
Priority
Select the priority level from the list. VLAN must be enabled
in order to set priority.
The 802.1p will be included in the VLAN header of the
packets which are received from the SSID and sent from
Ethernet or WDS interface.
WMM
Enable or disable WMM.
WMM (Wi-Fi Multimedia) is a component of the IEEE
802.11e wireless LAN standard for QoS.
WMM provides prioritization of wireless data packets from
different applications based on four access categories:
voice, video, best effort, and background. For an application
to receive the benefits of WMM QoS, both it and the client
running that application have to have WMM enabled.
Legacy applications that do not support WMM and
applications that do not require QoS, are assigned to the
best effort category, which receives a lower priority than
voice and video.
WMM is enabled by default.
53

Linksys LAPAC2600 Specifications

General

2.4 GHz	Yes
Frequency band	2.412 - 2.462, 5.18 - 5.24, 5.745 - 5.825 GHz
Channels quantity	13 channels
Number of VLAN IDs	17
Fit AP mode features	Wireless distribution system (WDS)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.1x, IEEE 802.3at
Receiver sensitivity	802.11b 11Mbps: -85dBm 802.11a/g 54Mbps: -73dBm 802.11n HT20 MCS7: -67dBm 802.11n HT40 MCS7: -65dBm 802.11n HT40 MCS7: -65dBm
Virtual LAN features	SSID-based VLAN assignment
Wi-Fi data rate (max)	1733 Mbit/s
Ethernet LAN data rates	1000 Mbit/s
Maximum data transfer rate	2533 Mbit/s
Output current	2.5 A
Output voltage	12 V
Power consumption (max)	25 W
Internal	No
Placement	Ceiling, Wall
Certification	FCC: 47 CFR FCC Part 15, Subpart B, Class B; 47 CFR FCC Part 15, Subpart C; 47 CFR FCC Part 15, Subpart E CE: EN55022, Class B; EN61000-3-2; EN61000-3-3; 55024; EN 301 489-1 / EN 301 489-17, Class B; EN 300 328; EN 301 893; EN 62311; EN 50385
Product color	White
LED indicators	System
Cable lock slot type	Kensington
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Antenna features	Integrated antenna
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Security algorithms	802.1x RADIUS, HTTPS, SNMP, WPA, WPA2
Number of SSID supported	16
Service Set Identifier (SSID) features	Hidden SSID
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	243 mm
Width	237 mm
Height	43.69 mm
Weight	848 g
