Linksys LAPAC2600 User Manual

Remote MAC
Address
MAC address of the access point on the other end of the
WDS link. Optional
WDS Station connects to remote WDS Root by matching
SSIDs. When there is more than one remote WDS Root with
the same SSID, the WDS Station can differentiate them by
MAC address.
The format is xx:xx:xx:xx:xx:xx.
VLAN List
Enter the list of VLANs that are accepted by the WDS
Station.
When VLAN is enabled, the WDS Station forwards to the
remote WDS Root only packets in the VLAN list. Packets
not in the VLAN list cannot be forwarded to the remote
WDS Root.
The VLAN List is only applicable when VLAN is enabled.
The VLAN list includes 1 to 8 VLAN IDs separated by ","
such as "100,200,300,400,500,600,700,800".
Security Mode
The type of encryption to use on the WDS link. It must be
unique to the access point on the other end of the WDS link.
The options are Disabled, WPA Personal, WPA2 Personal,
WPA Enterprise or WPA2 Enterprise.
Status
Status of the WDS interface. It can be Disabled, Connected
or Not Connected.
57

Linksys LAPAC2600 Specifications

General

2.4 GHz	Yes
Frequency band	2.412 - 2.462, 5.18 - 5.24, 5.745 - 5.825 GHz
Channels quantity	13 channels
Number of VLAN IDs	17
Fit AP mode features	Wireless distribution system (WDS)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.1x, IEEE 802.3at
Receiver sensitivity	802.11b 11Mbps: -85dBm 802.11a/g 54Mbps: -73dBm 802.11n HT20 MCS7: -67dBm 802.11n HT40 MCS7: -65dBm 802.11n HT40 MCS7: -65dBm
Virtual LAN features	SSID-based VLAN assignment
Wi-Fi data rate (max)	1733 Mbit/s
Ethernet LAN data rates	1000 Mbit/s
Maximum data transfer rate	2533 Mbit/s
Output current	2.5 A
Output voltage	12 V
Power consumption (max)	25 W
Internal	No
Placement	Ceiling, Wall
Certification	FCC: 47 CFR FCC Part 15, Subpart B, Class B; 47 CFR FCC Part 15, Subpart C; 47 CFR FCC Part 15, Subpart E CE: EN55022, Class B; EN61000-3-2; EN61000-3-3; 55024; EN 301 489-1 / EN 301 489-17, Class B; EN 300 328; EN 301 893; EN 62311; EN 50385
Product color	White
LED indicators	System
Cable lock slot type	Kensington
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Antenna features	Integrated antenna
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Security algorithms	802.1x RADIUS, HTTPS, SNMP, WPA, WPA2
Number of SSID supported	16
Service Set Identifier (SSID) features	Hidden SSID
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	243 mm
Width	237 mm
Height	43.69 mm
Weight	848 g
