Page #59 background imageLoading...
Page #59 background image
Workgroup Bridge
Radio
Select the desired radio from the list.
Radio 1 is for 2.4 GHz, and Radio 2 is for 5 GHz.
Workgroup Bridge Status
Status
Enable or disable Workgroup Bridge function.
Before configuring Workgroup Bridge, make sure all devices
in Workgroup Bridge have the following identical settings.
Radio
IEEE 802.11 Mode
Channel Bandwidth
Channel
NoteIt is highly recommended that static channel is
configured on both APs. Do not use the Auto channel option
when you enable Workgroup Bridge, as both APs in a
Workgroup Bridge link must be on the same radio channel. If
Auto option is configured, there is a chance two access
points will run on different channels which prevents
Workgroup Bridge link from being established.
Remote AP Settings
SSID
Enter the name of the SSID to which Workgroup Bridge will
connect. Click Site Survey to choose from the list. You
must do this for Workgroup Bridge to connect to a remote
access point.
Remote MAC
Address
Normally, Workgroup Bridge connects to a remote access
point by matching SSID. When more than one remote
access point has the same SSID, Workgroup Bridge can
connect to different remote access points.
Optional: You can specify the MAC address of the remote
access point to limit Workgroup Bridge’s connection to a
specific remote access point.
The format is xx:xx:xx:xx:xx:xx.
59

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Linksys LAPAC2600 and is the answer not in the manual?

Linksys LAPAC2600 Specifications

General IconGeneral
2.4 GHzYes
Frequency band2.412 - 2.462, 5.18 - 5.24, 5.745 - 5.825 GHz
Channels quantity13 channels
Number of VLAN IDs17
Fit AP mode featuresWireless distribution system (WDS)
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.1x, IEEE 802.3at
Receiver sensitivity802.11b 11Mbps: -85dBm 802.11a/g 54Mbps: -73dBm 802.11n HT20 MCS7: -67dBm 802.11n HT40 MCS7: -65dBm 802.11n HT40 MCS7: -65dBm
Virtual LAN featuresSSID-based VLAN assignment
Wi-Fi data rate (max)1733 Mbit/s
Ethernet LAN data rates1000 Mbit/s
Maximum data transfer rate2533 Mbit/s
Output current2.5 A
Output voltage12 V
Power consumption (max)25 W
InternalNo
PlacementCeiling, Wall
CertificationFCC: 47 CFR FCC Part 15, Subpart B, Class B; 47 CFR FCC Part 15, Subpart C; 47 CFR FCC Part 15, Subpart E CE: EN55022, Class B; EN61000-3-2; EN61000-3-3; 55024; EN 301 489-1 / EN 301 489-17, Class B; EN 300 328; EN 301 893; EN 62311; EN 50385
Product colorWhite
LED indicatorsSystem
Cable lock slot typeKensington
USB 2.0 ports quantity0
Ethernet LAN (RJ-45) ports2
Antenna featuresIntegrated antenna
Storage temperature (T-T)-20 - 70 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)10 - 85 %
Security algorithms802.1x RADIUS, HTTPS, SNMP, WPA, WPA2
Number of SSID supported16
Service Set Identifier (SSID) featuresHidden SSID
Cables includedLAN (RJ-45)
Weight and Dimensions IconWeight and Dimensions
Depth243 mm
Width237 mm
Height43.69 mm
Weight848 g
