Linksys LAPAC2600 User Manual

Profile
Select a profile to configure.
New Logo Upload
Logos display in the web page. Select an image file
from your local PC and click Upload.
Formats .gif, .png and .jpg are supported. File size
cannot exceed 5KB.
One profile can support one default and one new logo
image. If a second new logo is uploaded, it will replace
the first new logo.
Logo Selection
Select a logo image from the list.
Background Color
The HTML code for the background color in 6-digit
hexadecimal format. The default is #0073BA.
Font Color
The HTML code for the font color in 6-digit
hexadecimal format. The default is #FFFFFF.
Welcome Title
Customize text to go with your logo. The default is
Welcome to the Wireless Network.
Login Instruction
Customize text to go with the login box. Default text
for different authentication options:
Local Authentication/Radius Authentication
You can login using your username and password.
Password Only Authentication
You can login using your password.
Local Authentication
Click Connect to login.
User Label
Customize the username text box. Enter up to 16
characters. The default is Username.
Password Label
Customize the user password text box. Enter up to
16 characters. The default is Password.
Button Name
Customize the text that appears in the log in button.
Enter up to 12 characters. The default is Connect.
Button Color
The HTML code for the background color of the
button in 6-digit hexadecimal format. The default is
#70A0D4.
Terms of Use Label
Customize the text to go with the checkbox. Enter up
to 128 characters. The default is Check here to
indicate that you have read and accepted the
following Terms of Use.
72

Linksys LAPAC2600 Specifications

General

2.4 GHz	Yes
Frequency band	2.412 - 2.462, 5.18 - 5.24, 5.745 - 5.825 GHz
Channels quantity	13 channels
Number of VLAN IDs	17
Fit AP mode features	Wireless distribution system (WDS)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.1x, IEEE 802.3at
Receiver sensitivity	802.11b 11Mbps: -85dBm 802.11a/g 54Mbps: -73dBm 802.11n HT20 MCS7: -67dBm 802.11n HT40 MCS7: -65dBm 802.11n HT40 MCS7: -65dBm
Virtual LAN features	SSID-based VLAN assignment
Wi-Fi data rate (max)	1733 Mbit/s
Ethernet LAN data rates	1000 Mbit/s
Maximum data transfer rate	2533 Mbit/s
Output current	2.5 A
Output voltage	12 V
Power consumption (max)	25 W
Internal	No
Placement	Ceiling, Wall
Certification	FCC: 47 CFR FCC Part 15, Subpart B, Class B; 47 CFR FCC Part 15, Subpart C; 47 CFR FCC Part 15, Subpart E CE: EN55022, Class B; EN61000-3-2; EN61000-3-3; 55024; EN 301 489-1 / EN 301 489-17, Class B; EN 300 328; EN 301 893; EN 62311; EN 50385
Product color	White
LED indicators	System
Cable lock slot type	Kensington
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Antenna features	Integrated antenna
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Security algorithms	802.1x RADIUS, HTTPS, SNMP, WPA, WPA2
Number of SSID supported	16
Service Set Identifier (SSID) features	Hidden SSID
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	243 mm
Width	237 mm
Height	43.69 mm
Weight	848 g
