Linksys LAPAC2600 User Manual

Status
Disabled—Cluster function is disabled.
Active—Cluster function is enabled and master is active.
Active (Backup Master)—
Cluster function is enabled and backup master
is active.
Inactive (Cannot reach the master)—Cluster function is enabled but it's
inactive because device cannot reach the master.
Member Number
Number of the active members in the cluster. If an access point joins the
cluster but is powered off or cannot reach the master, it is not counted.
Location (Optional)
Where the access point is physically located; for example, Reception.
Length is from 0 to 32 bytes.
Cluster Name
Name of the cluster for the LAP device to join; for example, “lab cluster”.
All access points with the same cluster name belong to the same
cluster. Length of this value is from 4 to 32 bytes and special
characters are allowed. This is a mandatory field if the cluster function
is turned on.
Backup Master
When an access point works as a cluster slave, it can be enabled as a
backup master. When master gets offline, it will take the role of master.
When the backup master begins to work, it will send advertisements
and slaves will send keep-alive and report sessions to it. When
shareable settings are modified in it, it will share them to all slaves.
When master gets online again, this backup master AP will stop the
master function and let original master AP take over master role.
87

Linksys LAPAC2600 Specifications

General

2.4 GHz	Yes
Frequency band	2.412 - 2.462, 5.18 - 5.24, 5.745 - 5.825 GHz
Channels quantity	13 channels
Number of VLAN IDs	17
Fit AP mode features	Wireless distribution system (WDS)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.1x, IEEE 802.3at
Receiver sensitivity	802.11b 11Mbps: -85dBm 802.11a/g 54Mbps: -73dBm 802.11n HT20 MCS7: -67dBm 802.11n HT40 MCS7: -65dBm 802.11n HT40 MCS7: -65dBm
Virtual LAN features	SSID-based VLAN assignment
Wi-Fi data rate (max)	1733 Mbit/s
Ethernet LAN data rates	1000 Mbit/s
Maximum data transfer rate	2533 Mbit/s
Output current	2.5 A
Output voltage	12 V
Power consumption (max)	25 W
Internal	No
Placement	Ceiling, Wall
Certification	FCC: 47 CFR FCC Part 15, Subpart B, Class B; 47 CFR FCC Part 15, Subpart C; 47 CFR FCC Part 15, Subpart E CE: EN55022, Class B; EN61000-3-2; EN61000-3-3; 55024; EN 301 489-1 / EN 301 489-17, Class B; EN 300 328; EN 301 893; EN 62311; EN 50385
Product color	White
LED indicators	System
Cable lock slot type	Kensington
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Antenna features	Integrated antenna
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Security algorithms	802.1x RADIUS, HTTPS, SNMP, WPA, WPA2
Number of SSID supported	16
Service Set Identifier (SSID) features	Hidden SSID
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	243 mm
Width	237 mm
Height	43.69 mm
Weight	848 g
