Linksys LAPAC2600 User Manual

System Summary
Device SKU
The SKU is often used to identify device model number
and region.
Firmware Version
The version of the firmware currently installed.
Firmware
Checksum
The checksum of the firmware running in the access
point.
Hardware Version
The version of the hardware.
Local MAC
Address
The MAC (physical) address of the wireless access
point.
Serial Number
The serial number of the device.
Host Name
The host name assigned to the access point.
System Up Time
How long the system has been running since the last
restart or reboot.
System Time
The current date and time.
Power Source
The power source of the access point. It can be Power
over Ethernet (PoE) or Power Adapter. When two power
sources are plugged in, Power Adaptor will be
displayed.
LAG Status
Indicates the status of LAG (Link Aggregation). It can
be "Inactive" or "Active"
• When LAG is inactive, only one Ethernet port
works at a given time.
• LAG only works when link speed and duplex of
the two Ethernet ports are the same and duplex
must be Full. LACP does not support half-
duplex.
• LAG is based on 802.3ad LACP (Link
Aggregation Control Protocol) so it works only
when link ends of the two Ethernet ports of the
Access Ports also support 802.3ad LACP and
enable it.
93

Linksys LAPAC2600 Specifications

General

2.4 GHz	Yes
Frequency band	2.412 - 2.462, 5.18 - 5.24, 5.745 - 5.825 GHz
Channels quantity	13 channels
Number of VLAN IDs	17
Fit AP mode features	Wireless distribution system (WDS)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.1x, IEEE 802.3at
Receiver sensitivity	802.11b 11Mbps: -85dBm 802.11a/g 54Mbps: -73dBm 802.11n HT20 MCS7: -67dBm 802.11n HT40 MCS7: -65dBm 802.11n HT40 MCS7: -65dBm
Virtual LAN features	SSID-based VLAN assignment
Wi-Fi data rate (max)	1733 Mbit/s
Ethernet LAN data rates	1000 Mbit/s
Maximum data transfer rate	2533 Mbit/s
Output current	2.5 A
Output voltage	12 V
Power consumption (max)	25 W
Internal	No
Placement	Ceiling, Wall
Certification	FCC: 47 CFR FCC Part 15, Subpart B, Class B; 47 CFR FCC Part 15, Subpart C; 47 CFR FCC Part 15, Subpart E CE: EN55022, Class B; EN61000-3-2; EN61000-3-3; 55024; EN 301 489-1 / EN 301 489-17, Class B; EN 300 328; EN 301 893; EN 62311; EN 50385
Product color	White
LED indicators	System
Cable lock slot type	Kensington
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Antenna features	Integrated antenna
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Security algorithms	802.1x RADIUS, HTTPS, SNMP, WPA, WPA2
Number of SSID supported	16
Service Set Identifier (SSID) features	Hidden SSID
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	243 mm
Width	237 mm
Height	43.69 mm
Weight	848 g
