Linksys LAPAC2600 User Manual

VLAN
VLAN
Enabled or disabled (default).
Untagged VLAN
Enabled (default) or disabled.
When enabled, and if its VLAN ID is equal to Untagged
VLAN ID, all traffic is untagged when sent from LAN
ports. Untagged traffic can be accepted by LAN ports. If
disabled, traffic is always tagged when sent from LAN
port and only tagged traffic can be accepted from LAN
port.
By default, all traffic on the access point uses VLAN 1,
the default untagged VLAN. This means that all traffic is
untagged until you disable the untagged VLAN, change
the untagged traffic VLAN ID, or change the VLAN ID for
a SSID.
Untagged VLAN
ID
Displays the untagged VLAN ID. Traffic on the VLAN
that you specify in this field is not be tagged with a VLAN
ID when forwarded to the network. VLAN 1 is the default
ID for untagged VLAN and management VLAN.
Management
VLAN
Displays the Management VLAN ID. The VLAN
associated with the IP address you use to connect to the
access point. Provide a number between 1 and 4094 for
the Management VLAN ID. The default is 1.
This VLAN is also the default untagged VLAN. If you
already have a management VLAN configured on your
network with a different VLAN ID, you must change the
VLAN ID of the management VLAN on the access point.
96

Linksys LAPAC2600 Specifications

General

2.4 GHz	Yes
Frequency band	2.412 - 2.462, 5.18 - 5.24, 5.745 - 5.825 GHz
Channels quantity	13 channels
Number of VLAN IDs	17
Fit AP mode features	Wireless distribution system (WDS)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.1x, IEEE 802.3at
Receiver sensitivity	802.11b 11Mbps: -85dBm 802.11a/g 54Mbps: -73dBm 802.11n HT20 MCS7: -67dBm 802.11n HT40 MCS7: -65dBm 802.11n HT40 MCS7: -65dBm
Virtual LAN features	SSID-based VLAN assignment
Wi-Fi data rate (max)	1733 Mbit/s
Ethernet LAN data rates	1000 Mbit/s
Maximum data transfer rate	2533 Mbit/s
Output current	2.5 A
Output voltage	12 V
Power consumption (max)	25 W
Internal	No
Placement	Ceiling, Wall
Certification	FCC: 47 CFR FCC Part 15, Subpart B, Class B; 47 CFR FCC Part 15, Subpart C; 47 CFR FCC Part 15, Subpart E CE: EN55022, Class B; EN61000-3-2; EN61000-3-3; 55024; EN 301 489-1 / EN 301 489-17, Class B; EN 300 328; EN 301 893; EN 62311; EN 50385
Product color	White
LED indicators	System
Cable lock slot type	Kensington
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Antenna features	Integrated antenna
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Security algorithms	802.1x RADIUS, HTTPS, SNMP, WPA, WPA2
Number of SSID supported	16
Service Set Identifier (SSID) features	Hidden SSID
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	243 mm
Width	237 mm
Height	43.69 mm
Weight	848 g
