30
Security Settings - WPA2-Enterprise
This version of WPA2-Enterprise requires a RADIUS Server on your LAN to provide the
client authentication. Data transmissions are encrypted using the WPA2 standard.
Figure 21: WPA2-Enterprise Wireless Security Screen
Data - WPA2-Enterprise Screen
WPA2-Enterprise
Primary Server
Enter the IP address of the RADIUS Server on your network.
Primary Server Port
Enter the port number used for connections to the RADIUS
Server. It is a value from 1 to 65534, and default is 1812.
Primary Shared Secret
Enter the key value to match the RADIUS Server. It consists of
1 to 64 characters.
Backup Server
The Backup Authentication Server will be used when the
Primary Authentication Server is not available.
Backup Server Port
Enter the port number used for connections to the Backup
RADIUS Server. It’s a value from 1 to 65534, and default is
1812.
Backup Shared Secret
Enter the key value to match the Backup RADIUS Server. It
consists of 1 to 64 characters.
WPA Algorithm
The encryption method is AES.
