Linksys RE1000 Getting Started

12
Getting Started
RE1000 Range Extender
3. Click your own network name, then click Connect. In the example
below, the computer was connected to another wireless network named
JimsRouter. The name of the correct network, BronzeEagle in this example,
is shown selected.
4. If you are prompted to enter a network key, type your password (Security
Key) into the Network key and Confirm network key fields, then click
Connect.
Your computer connects to the network, and you should now be able to
access the range extender’s browser-based utility.
To fix the problem on Mac computers:
1. In the menu bar across the top of the screen, click the AirPort icon. A list
of wireless networks appears. Cisco Connect has automatically assigned
your network a name.
In the example below, the computer was connected to another wireless
network named JimsRouter. The name of the Linksys E-Series network,
BronzeEagle in this example, is shown selected.
2. Click the wireless network name of the router your range extender is
connected to.
3. Type your wireless network password (Security Key) into the Password
field, then click OK.
Your computer connects to the network, and you should now be able to
access the range extender’s browser-based utility.

Linksys RE1000 Specifications

General

Maximum data transfer rate	100 Mbit/s
Supported data transfer rates	10/100 Mbit/s
Frequency band	2.4 GHz
DC-in jack	Yes
Connectivity technology	Wireless
Ethernet LAN (RJ-45) ports	1
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Minimum system requirements	Internet Explorer 7, Safari 4, Firefox 3
Compatible operating systems	Windows XP SP3, Windows Vista SP1, Windows 7 OS X Leopard 10.5, Snow Leopard 10.6
AC input frequency	50 - 60 Hz
Power requirements	100 - 240, 50/60 Hz
