Linksys RE1000 Getting Started

14
Memulai
RE1000 Range Extender
Spesifikasi
Nama Model Linksys RE1000
Keterangan Model Wireless-N Extender
Nomor Model RE1000
Standar IEEE 802.11n, 802.11g, 802.11b, 802.3u
Port Fast Ethernet, konektor C7 untuk kabel atau
klip AC lokal
Tombol Reset, Wi-Fi Protected Setup™
LED Wi-Fi Protected Setup, Ethernet (active, trac)
Jenis Kabel CAT 5
Antena 2 (internal)
Lepas-pasang (y/t) Tidak
Daya Transmisi 802.11n (40 MHz) 15,5 ± 1,5
dBm @ CH6, mcs15
802.11n (20 MHz) 17,0 ± 1,5
dBm @ CH6, mcs 0-4, mcs 8-12
802.11n (20 MHz) 16,0 ± 1,5
dBm @ CH6, mcs 5-7, mcs 13-15
802.11g 18,0 ± 1,5 dBm
802.11b 18,0 ± 1,5 dBm
Sensitivitas Penerimaan -91 dBm @ 1 Mbps
-87 dBm @ 11 Mbps
-71 dBm @ 54 Mbps
-66 dBm @ 270 Mbps
Penguatan Antena 3,5 dBi
Keamanan Nirkabel Wi-Fi Protected Access™ 2 (WPA2), WEP
Bit Kunci Keamanan Enkripsi hingga 128-bit
Lingkungan
Dimensi 4,92” x 3,62” x 1,29” (125 x 92 x 33 mm)
Berat 9,9 oz (280 g)
Daya Catu daya AC/DC internal
100-240 V, 50/60 Hz, 0,5 A
Sertikasi FCC, UL/cUL, ICES-003, RSS210, CE,
Wi-Fi a/b/g/n, Wi-Fi, (IEEE802.11b/g/n),
WPA2™, WMM®, Wi-Fi Protected Setup™
Suhu Pengoperasian 32 hingga 104°F (0 hingga 40°C)
Suhu Penyimpanan -4 hingga 140°F (-20 hingga 60°C)
Kelembapan Pengoperasian 10 hingga 80% non-kondensasi
Kelembapan Penyimpanan 5 hingga 90% non-kondensasi
Spesikasi dapat berubah sewaktu-waktu tanpa pemberitahuan.

Linksys RE1000 Specifications

General

Maximum data transfer rate	100 Mbit/s
Supported data transfer rates	10/100 Mbit/s
Frequency band	2.4 GHz
DC-in jack	Yes
Connectivity technology	Wireless
Ethernet LAN (RJ-45) ports	1
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Minimum system requirements	Internet Explorer 7, Safari 4, Firefox 3
Compatible operating systems	Windows XP SP3, Windows Vista SP1, Windows 7 OS X Leopard 10.5, Snow Leopard 10.6
AC input frequency	50 - 60 Hz
Power requirements	100 - 240, 50/60 Hz
