Linksys RE1000 Getting Started

14
Getting Started
RE1000 Range Extender
Specifications
Model Name Linksys RE1000
Model Description Wireless-N Extender
Model Number RE1000
Standards IEEE 802.11n, 802.11g, 802.11b, 802.3u
Ports Fast Ethernet, C7 connector for localized
AC cable or clip
Buttons Reset, Wi-Fi Protected Setup™
LEDs Wi-Fi Protected Setup, Ethernet (active, trac)
Cabling Type CAT 5
Antennas 2 (internal)
Detachable (y/n) No
Transmitted Power 802.11n (40 MHz) 15.5 ± 1.5
dBm @ CH6, mcs15
802.11n (20 MHz) 17.0 ± 1.5
dBm @ CH6, mcs0-4, mcs8-12
802.11n (20 MHz) 16.0 ± 1.5
dBm @ CH6, mcs5-7, mcs13-15
802.11g 18.0 ± 1.5 dBm
802.11b 18.0 ± 1.5 dBm
Receive Sensitivity -91 dBm @ 1 Mbps
-87 dBm @ 11 Mbps
-71 dBm @ 54 Mbps
-66 dBm @ 270 Mbps
Antenna Gain 3.5 dBi
Wireless Security Wi-Fi Protected Access™ 2 (WPA2), WEP
Security Key Bits Up to 128-bit encryption
Environmental
Dimensions 4.92” x 3.62” x 1.29” (125 x 92 x 33 mm)
Weight 9.9 oz (280 g)
Power Internal AC/DC power supply
100-240V, 50/60Hz, 0.5A
Certication FCC, UL/cUL, ICES-003, RSS210, CE,
Wi-Fi a/b/g/n, Wi-Fi, (IEEE802.11b/g/n),
WPA2™, WMM®, Wi-Fi Protected Setup™
Operating Temperature 32 to 104°F (0 to 40°C)
Storage Temperature -4 to 140°F (-20 to 60°C)
Operating Humidity 10 to 80% noncondensing
Storage Humidity 5 to 90% noncondensing
Specications are subject to change without notice.

Linksys RE1000 Specifications

General

Maximum data transfer rate	100 Mbit/s
Supported data transfer rates	10/100 Mbit/s
Frequency band	2.4 GHz
DC-in jack	Yes
Connectivity technology	Wireless
Ethernet LAN (RJ-45) ports	1
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Minimum system requirements	Internet Explorer 7, Safari 4, Firefox 3
Compatible operating systems	Windows XP SP3, Windows Vista SP1, Windows 7 OS X Leopard 10.5, Snow Leopard 10.6
AC input frequency	50 - 60 Hz
Power requirements	100 - 240, 50/60 Hz
