14
WPS
WPS makes it easy to connect your range extender to your network and connect other devices to
your network through the range extender.
Connecting the range extender to an existing access point or wireless router
(see p. 5)
Connecting devices to your network through the range extender
Repeat the instructions for each client device that supports WPS.
1.
Connecting with the WPS Button
a.
Press the WPS button on the client device.
b.
Press and hold the WPS button on the side of the range extender for one second OR
click the WPS button on the WPS screen in the range extender’s browser-based
settings. The light on the front of the range extender will blink blue until pairing is
complete. If the light blinks orange, the connection failed. Go back to previous step
and try again.
c.
If using the range extender’s WPS screen, be sure to click OK within two minutes or
you will have to start over.
2.
Connecting with the client device’s PIN
