10
Chapter 3: Getting to Know the Router
The Back and Side Panels
10/100 4-Port VPN Router
The power port is located on the right side panel of the Router.
Power The Power port is where you will connect the included AC power cable.
‘
The security slot is located on the left side panel.
Security Slot The security slot is where you can attach a lock so the Router will be protected from
theft.
Proceed to “Chapter 4: Connecting the Router.”
Figure 3-3: Right Side Panel
Figure 3-4: Left Side Panel
