58
Chapter 6: Set Up and Configure the Router
Wizard Tab
10/100 4-Port VPN Router
5. The next screen that appears depends on your WAN (or Internet) Connection Type selection for your WAN1
port.
If you chose Obtain an IP automatically, Figure 6-56 appears. Select Use DNS Server provided by ISP
(default) or Use the Following DNS Server Addresses, if you want to enter a specific IP. Click Next to
continue. Click Previous if you want to return to the previous screen. Click Exit if you want to exit the wizard.
If you chose Static IP, Figure 6-55 appears. Enter the Static IP, Subnet Mask, and Default Gateway provided
by your ISP. Click Next to continue. Click Previous if you want to return to the previous screen. Click Exit if
you want to exit the wizard.
If you chose PPPoE, Figure 6-56 appears. Enter the User Name and Password provided by your ISP. Click
Next to continue. Click Previous if you want to return to the previous screen. Click Exit if you want to exit the
wizard.
Figure 6-54: Obtain an IP Automatically
Figure 6-55: Static IP
Figure 6-56: PPPoE
