Chapter 2: Product Overview
6
16-Port and 24-Port 10/100 Switches
Back Panel
The Ethernet network ports are located on the back panel of the
Switch.
Back Panel of the 16-Port Switch
(power) The power port is where you will connect the included
power cord.
Side Panel
The security slot is located on the side panel of the Switch.
Side Panel with Security Slot
(security slot) The security slot is where you can attach a lock
to protect the Switch from theft.
