Wall-mount
To hang the Switch on a wall, follow these instructions:
The wall-mount slots are two crisscross slots on the Switch’s bottom
panel (see Figure 3-3). The distance between the two slots is 95 mm.
Attach two screws to the wall, so that the Switch’s wall-mount slots
line up with the two screws.
3.74 in
(95 mm)
Wall-mount Slots
Maneuver the Switch so the screws are inserted into the two slots.
1.
2.
