Chapter 5: Using the Web-based Utility for Configuration
Security Tab - ACL Binding
WebView Switches
Security Tab - ACL Binding
When an ACL is bound to an interface, all the ACE rules that have been defined are applied to the selected
interface.Whenever an ACL is assigned on a port, LAG or, VLAN, flows from that ingress interface that do not
match the ACL are matched to the default rule, which is Drop unmatched packets.
Interface. Indicates the interface to which the ACL is bound.
ACL Name. Indicates the ACL which is bound to the interface.
The Add to List button adds the ACL Binding configuration to the ACL Binding Table at the bottom of the screen.
Security Tab - RADIUS
Remote Authorization Dial-In User Service (RADIUS) servers provide additional security for networks. RADIUS
servers provide a centralized authentication method for web access.
IP Address. The Authentication Server IP address.
Priority. The server priority. The possible values are 0-65535, where 1 is the highest value. The RADIUS Server
priority is used to configure the server query order.
Authentication Port. Identifies the authentication port. The authentication port is used to verify the RADIUS
server authentication. The authenticated port default is 1812.
Number of Retries. Defines the number of transmitted requests sent to RADIUS server before a failure occurs.
The possible field values are 1 - 10. Three is the default value.
Timeout for Reply. Defines the amount of the time in seconds the device waits for an answer from the RADIUS
server before retrying the query, or switching to the next server. The possible field values are 1 - 30. Three is the
default value.
Figure 5-29: Security - RADIUS
Figure 5-28: Security - ACL Binding
