54
Chapter 5: Using the Web-based Utility for Configuration
Security Tab - 802.1x Settings
WebView Switches
Timeout for Reply. Displays the amount of time that passes before the connection between the device and the
TACACS+ server times out. The field range is 1-30 seconds.
Status. Displays the connection status between the device and the TACACS+ server. The possible field values
are:
• Connected. There is currently a connection between the device and the TACACS+ server.
• Not Connected. There is not currently a connection between the device and the TACACS+ server.
Single Connection. Maintains a single open connection between the device and the TACACS+ server when
selected
The Add to List button adds the TACACS+ configuration to the TACACS+ table at the bottom of the screen.
Security Tab - 802.1x Settings
Port based authentication enables authenticating system users on a per-port basis via an external server. Only
authenticated and approved system users can transmit and receive data. Ports are authenticated via the RADIUS
server using the Extensible Authentication Protocol (EAP).
Enable 802.1x. Place a checkmark in the check box to enable 802.1x authentication.
Port. Indicates the port name.
Status Port Control. Specifies the port authorization state. The possible field values are as follows:
• Force-Authorized. The controlled port state is set to Force-Authorized (forward traffic).
• Force-Unauthorized. The controlled port state is set to Force-Unauthorized (discard traffic).
Enable Periodic Reauthentication. Permits immediate port reauthentication.
The Setting Timer button opens the Setting Timer screen to configure ports for 802.1x functionality.
Figure 5-31: Security - 802.1x Settings
